This machine is sold
Profile bending machine PBT - 25 PC TOUCH 200
MACH-ID 8778| Make: | PBT |
| Type: | 25 PC TOUCH 200 |
| Year: | 2004 |
- 3 roll driven
- Interpolation
- Roll height 300 mm
- Radius measuring system
- Power X-Axis 3 kW
Specifications
Horizontal and vertical
Horizontal & Vertical
Horizontal & Vertical
Shaft Ø
105 mm
4.134 inch
Number of rolls
3
3
Stroke X-Axis
265 mm
10.433 inch
Capacity flat
80 x 80 x R=1000 mm
80 x 80 x R=1000 inch
Capacity Tube
114 x 3 x R = 2000 Ø x mm
114 x 3 x R = 2000 Ø x mm
Capacity bar
60 x 60 x R=1000 mm
60 x 60 x R=1000 inch
Capacity T-Profile
80 x 80 x 8 x R=1000 mm
80 x 80 x 8 x R=1000 inch
Working speed
1 - 24.000 mm/min.
1 - 24.000 mm/min.
Control
PC 200
PC 200
Dimensions (Estimate)
Length
1500 mm
59.055 inch
Width
1200 mm
47.244 inch
Height
1400 mm
55.118 inch
Weight
1200 kg
2646.7 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
