CNC Lathe with c-axis MORI SEIKI - SL 200 SMC

MACH-ID 8585

Make:	MORI SEIKI
Type:	SL 200 SMC
Control:	MAPPS FANUC
Year:	1998

Whatsapp question

Sub spindel
All ATC with Live tooling
C Axis 360.000
LNS Hydrobar vbar feeder
Power on hours 4700 H
Running 2000 H

Specifications

Metric US Standard

Max. turning Ø 680 mm 26.772 inch

X-Axis 235 mm 9.252 inch

Z-Axis 495 mm 19.488 inch

B Axis 505 ° 505 °

Spindle bore 51 mm 2.008 inch

Speedrange 4000 Rpm 4000 Rpm

Spindle power 12 kW 12 kW

Subspindle speeds 3000 Rpm 3000 Rpm

Subspindle bore 62 mm 2.441 inch

Subspindle power 10 kW 10 kW

ATC / revolver 12 12

Speed live tools 4000 Rpm 4000 Rpm

Power live tools 5,5 kW 5,5 kW

Dimensions (Estimate)

Length 2800 mm 110.236 inch

Width 1800 mm 70.866 inch

Height 2300 mm 90.551 inch

Weight 5800 kg 12792.6 lbs

Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
