This machine is sold
Teach-in lathe WEILER - E 110
CNC Lathe Ø 1100 x 3000 mm MACH-ID 6837| Make: | WEILER |
| Type: | E 110 |
| Year: | 1999 |
Specifications
Swing over bed Ø
1100 mm
43.307 inch
Swing over cross slide Ø
730 mm
28.74 inch
DBC Turning Length
3000 mm
118.11 inch
Spindle bore
128 mm
5.039 inch
Spindle power
45 kW
45 kW
Bed width
600 mm
23.622 inch
Workpiece weight
6000
6000
Speeds / ranges
1200 Rpm
1200 Rpm
Feed rate X-Axis
10000 mm/min.
10000 mm/min.
Feed rate Z-Axis
5000 mm/min.
5000 mm/min.
Dimensions (Estimate)
Length
7100 mm
279.527 inch
Width
2400 mm
94.488 inch
Height
2650 mm
104.331 inch
Weight
12500 kg
27570.3 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
