This machine is sold
3-axis CNC machine (VMC) DECKEL MAHO - MH600E
MACH-ID 7672| Make: | DECKEL MAHO |
| Type: | MH600E |
| Control: | Philips 532 |
| Year: | 1993 |
Specifications
X - Travel
600 mm
23.622 inch
Y - Travel
450 mm
17.717 inch
Z - Travel
450 mm
17.717 inch
Table Length
740 mm
29.134 inch
Table Width
445 mm
17.52 inch
Table load
250
250
Feed rate X-Axis
10000 mm/min.
10000 mm/min.
Feed rate Y-Axis
10000 mm/min.
10000 mm/min.
Feed rate Z-Axis
10000 mm/min.
10000 mm/min.
Spindle Taper
40 ISO/Bt/Mk
40 ISO/Bt/Mk
Power on spindle
15 kW
15 kW
Speeds / ranges
5000 Rpm
5000 Rpm
ATC / revolver
22
22
Number of controlled axis
3
3
Dimensions (Estimate)
Length
3200 mm
125.984 inch
Width
2400 mm
94.488 inch
Height
2800 mm
110.236 inch
