3-axis CNC machine (VMC) EMCO Famup - VMC 70

MACH-ID 7505

Make:	EMCO Famup
Type:	VMC 70
Control:	SIEMENS 840D

Whatsapp question

Specifications

Metric US Standard

X - Travel 700 mm 27.559 inch

Y - Travel 500 mm 19.685 inch

Z - Travel 600 mm 23.622 inch

Table Length 1000 mm 39.37 inch

Table Width 520 mm 20.472 inch

Table load 700 700

Feed rate X-Axis 30000 mm/min. 30000 mm/min.

Feed rate Y-Axis 30000 mm/min. 30000 mm/min.

Feed rate Z-Axis 30000 mm/min. 30000 mm/min.

Spindle Taper 40 ISO/Bt/Mk 40 ISO/Bt/Mk

Power on spindle 15 kW 15 kW

Speeds / ranges 10000 Rpm 10000 Rpm

ATC / revolver 24 24

Chip conveyor Yes Yes

Coolantsystem Yes Yes

Dimensions (Estimate)

Length 4100 mm 161.417 inch

Width 2500 mm 98.425 inch

Height 2900 mm 114.173 inch

Weight 5700 kg 12572 lbs

Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
