5-axis CNC machine (VMC) Haas - UMC-750

MACH-ID 8501

Make:	Haas
Type:	UMC-750
Control:	HAAS
Year:	2019

Whatsapp question

The UMC-750 is a 5-axis 40-taper vertical machining center with
762" x 508" x 508" travels and an integrated dual-axis trunnion table.
The machine is equipped with a powerful 12000-rpm inline direct-drive
spindle driven by a 22-kW vector drive system, and comes
standard with a 40+1 tool side-mount tool changer.
The UMC-750’s 630 x 500 mm trunnion table features standard T-slots,
as well as a precision pilot bore, for fixturing versatility. The trunnion
provides +110 and -35 degrees of tilt and 360 degrees of rotation to
provide excellent tool clearance and large part capacity.

Specifications

Metric US Standard

X - Travel 762 mm 30 inch

Y - Travel 506 mm 19.921 inch

Z - Travel 506 mm 19.921 inch

A - Axis + 110 to - 35 ° + 110 to - 35 °

B - Axis 360000 ° 360000 °

Table Length 630 mm 24.803 inch

Table Width 500 mm 19.685 inch

Table load 300 300

Feed rate X-Axis 30500 mm/min. 30500 mm/min.

Feed rate Y-Axis 30500 mm/min. 30500 mm/min.

Feed rate Z-Axis 30500 mm/min. 30500 mm/min.

Feed rate A-Axis 3000 Degrees/min 3000 Degrees/min

Feed rate B-Axis 3000 Degrees/min 3000 Degrees/min

Spindle Taper 40 ISO/Bt/Mk 40 ISO/Bt/Mk

Power on spindle 22.4 kW 22.4 kW

Speeds / ranges 12000 Rpm 12000 Rpm

ATC / revolver 41 41

Coolant through spindle / Bar 25 25

Number of controlled axis 5 5

Chip conveyor Yes Yes

Coolantsystem Yes Yes

Dimensions (Estimate)

Length 3048 mm 120 inch

Width 4115 mm 162.008 inch

Height 2870 mm 112.992 inch

Weight 8400 kg 18527.2 lbs

Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
