5-axis CNC machine (VMC) MIKRON - UCP 800 DURO
MACH-ID 9753| Make: | MIKRON |
| Type: | UCP 800 DURO |
| Control: | HeidenHain iTNC530 |
| Year: | 2006 |
7.177,0 kg
CO2
will be saved when purchasing this machine
This is equivalent to:
3,59
return flights from Amst - New York
35.885,00
kilometers with a diesel car
7.974,00
kilometers with a truck
0,18
new-build houses
Specifications
X - Travel
800 mm
31.496 inch
Y - Travel
650 mm
25.591 inch
Z - Travel
500 mm
19.685 inch
A - Axis
+120 to -100 °
+120 to -100 °
B - Axis
360.000 °
360.000 °
Table Length
600 mm
23.622 inch
Table Width
600 mm
23.622 inch
Table load
500
500
Feed rate X-Axis
30000 mm/min.
30000 mm/min.
Feed rate Y-Axis
30000 mm/min.
30000 mm/min.
Feed rate Z-Axis
30000 mm/min.
30000 mm/min.
Spindle Taper
HSK63 ISO/Bt/Mk
HSK63 ISO/Bt/Mk
Power on spindle
18 kW
18 kW
Speeds / ranges
20000 Rpm
20000 Rpm
ATC / revolver
30
30
Coolant through spindle / Bar
20
20
Number of controlled axis
5
5
Chip conveyor
yes
yes
Coolantsystem
yes
yes
Dimensions (Estimate)
Length
3200 mm
125.984 inch
Width
2400 mm
94.488 inch
Height
3200 mm
125.984 inch
Weight
10000 kg
22056.2 lbs
