This machine is sold
Flanging and dishing machine GRAAF - HVP 300
MACH-ID 7656| Make: | GRAAF |
| Type: | HVP 300 |
| Year: | 1964 |
- Die height 1400 mm
- Ram size 400 mm
- Hydro pack 1800 x 1800 x 1200
Specifications
Capacity Kg
300
300
Distance between column
1700 mm
66.929 inch
Table Length
1500 mm
59.055 inch
Table Width
1500 mm
59.055 inch
Table Height
800 mm
31.496 inch
Ram stroke
900 mm
35.433 inch
Approche speed
4000 mm/min.
4000 mm/min.
Working speed
3000 mm/min.
3000 mm/min.
Return speed
4000 mm/min.
4000 mm/min.
Dimensions (Estimate)
Length
2500 mm
98.425 inch
Width
1500 mm
59.055 inch
Height
3840 mm
151.181 inch
Weight
15000 kg
33084.3 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
