This machine is sold
Tool grinding machine SCHNEEBERGER - GEMINI
MACH-ID 8816| Make: | SCHNEEBERGER |
| Type: | GEMINI |
| Control: | FANUC 160i-M |
| Year: | 2002 |
- Fanuc 5 Axis FANUC
- 370 Gr head rotatable
- Coolant filtration
- Connection power 21 kVA
Specifications
X - Travel
360 mm
14.173 inch
Y - Travel
270 mm
10.63 inch
Z - Travel
270 mm
10.63 inch
C - Axis Travel
370 (Resolution 0.0001) °
370 (Resolution 0.0001) °
A - Axis Travel
Resolution 0.0001 °
Resolution 0.0001 °
Spindle A-Axis
50 ISO / Mk / Hsk
50 ISO / Mk / Hsk
Centre height
210 mm
8.268 inch
Grinding wheel Ø
250
250
Grinding wheel power
7.5 kW
7.5 kW
Grinding speeds
9000 Rpm
9000 Rpm
Dimensions (Estimate)
Length
2100 mm
82.677 inch
Width
2300 mm
90.551 inch
Height
2050 mm
80.709 inch
Weight
5000 kg
11028.1 lbs
