This machine is sold
Sliding bed lathe ET BM CT 650
MACH-ID 3706| Type: | ET BM CT 650 |
| Year: | 1995 |
Specifications
Swing over bed Ø
1400 mm
55.118 inch
Swing over cross slide Ø
980 mm
38.583 inch
Swing in the gap Ø
2000 mm
78.74 inch
Spindle bore
150 mm
5.906 inch
Bed width
800 mm
31.496 inch
Power
60 kW
60 kW
Speeds / ranges
900 Rpm
900 Rpm
Dimensions (Estimate)
Length
10000 mm
393.7 inch
Width
3000 mm
118.11 inch
Height
3800 mm
149.606 inch
Weight
15000 kg
33084.3 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
incl. full C Axis
incl. milling attachment
incl. sauter 4 position revolver
incl. chip conveyor
incl. large tooling package
optional 4 chuck 1500 mm
optional steady rest 800 mm
optional steady rest 500 mm
