This machine is reserved
CNC Bed-Type Milling Machine Lagun Goratu - GBM 3
MACH-ID 9312| Make: | Lagun Goratu |
| Type: | GBM 3 |
| Control: | HeidenHain iTNC530 |
| Year: | 2017 |
16.522,8 kg
CO2
will be saved when purchasing this machine
This is equivalent to:
8,26
return flights from Amst - New York
82.614,00
kilometers with a diesel car
18.359,00
kilometers with a truck
0,41
new-build houses
- Incl. Chip conveyor
- incl. Coolant true spindel 20 Bar
- incl. Closed Giders with doors
- Optional 4e axis PHV-600 with Tailstock
- Optional Tool package BT-50
- Optional 3D Measuring Probe
- Around 7000 Hours
Specifications
X-Axis
3000 mm
118.11 inch
Y-Axis
1200 mm
47.244 inch
Z-Axis
1500 mm
59.055 inch
Table Length
3100 mm
122.047 inch
Table Width
1000 mm
39.37 inch
Table load
9000
9000
Power on spindle
34 kW
34 kW
Spindle speeds
4000 Rpm
4000 Rpm
Spindle Taper
ISO50 ISO/Bt/Mk
ISO50 ISO/Bt/Mk
Feed rate X-Axis
20000 mm/min.
20000 mm/min.
Feed rate Y-Axis
20000 mm/min.
20000 mm/min.
Feed rate Z-Axis
20000 mm/min.
20000 mm/min.
Millinghead auto-index
2.5 x 2.5 °
2.5 x 2.5 °
Working hours
7500 H
7500 H
Dimensions (Estimate)
Length
8090 mm
318.503 inch
Width
5770 mm
227.165 inch
Height
3770 mm
148.425 inch
Weight
20350 kg
44884.4 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
