This machine is sold
CNC milling machine Deckel - FP3NC
MACH-ID 8810| Make: | Deckel |
| Type: | FP3NC |
| Control: | Dialog 11 |
| Year: | 1982 |
Specifications
X-Axis
500 mm
19.685 inch
Y-Axis
400 mm
15.748 inch
Z-Axis
400 mm
15.748 inch
Table Length
700 mm
27.559 inch
Table Width
470 mm
18.504 inch
Table load
400
400
Spindle speeds
4000 Rpm
4000 Rpm
Feed rate X-Axis
4000 mm/min.
4000 mm/min.
Feed rate Y-Axis
4000 mm/min.
4000 mm/min.
Feed rate Z-Axis
4000 mm/min.
4000 mm/min.
Stroke pinole
90 mm
3.543 inch
Dimensions (Estimate)
Length
1900 mm
74.803 inch
Width
2000 mm
78.74 inch
Height
2200 mm
86.614 inch
Weight
1800 kg
3970.1 lbs
