4 roll plate bender HAEUSLER - VRM-HY
MACH-ID 9183| Make: | HAEUSLER |
| Type: | VRM-HY |
| Year: | 2009 |
- Force lower rol upper roll 1178 Ton
- Cone bending attachment
- Hardned and grounded rolls
- Width between upper and lower roll 200 mm
- Power 180 kW
Specifications
Rolling width
3050 mm
120.079 inch
Rolling thickness 3x toproll Ø
90 mm
3.543 inch
Rolling thickness 5x toproll Ø
100 mm
3.937 inch
Rolling thickness prebending
80 mm
3.15 inch
Top Roll Ø
840 mm
33.071 inch
Bottom Roll Ø
760 mm
29.921 inch
Side roll Ø
610 mm
24.016 inch
Number of rolls
4
4
Rolling speed
1,5 / 3 / 4,5 / 6 M/Min
1,5 / 3 / 4,5 / 6 M/Min
Adjustiment lower roll
0 - 300 mm/min.
0 - 300 mm/min.
Number of driven rolls
2
2
Power
180 kW
180 kW
Dimensions (Estimate)
Length
7500 mm
295.275 inch
Width
3250 mm
127.953 inch
Height
4250 mm
167.323 inch
Weight
130000 kg
286730.6 lbs
