Profile bending machine COMAC - 304 HV
Universal profile bending machine COMAC 304 HV MACH-ID 6380| Make: | COMAC |
| Type: | 304 HV |
| Year: | 2001 |
Specifications
Horizontal and vertical
H + V
H + V
Shaft Ø
60 mm
2.362 inch
Number of rolls
3
3
Resistance moment
10 CM³
10 CM³
Capacity flat
70 x 12 x R 600 mm
70 x 12 x R 600 inch
Capacity Tube
76,1 x 2,9 x R 1200 Ø x mm
76,1 x 2,9 x R 1200 Ø x mm
Capacity bar
40 x 40 x R 600 mm
40 x 40 x R 600 inch
Capacity T-Profile
70 x 70 x 8 x R 700 mm
70 x 70 x 8 x R 700 inch
Working speed
5,2 M/Min mm/min.
5,2 M/Min mm/min.
Dimensions (Estimate)
Length
1000 mm
39.37 inch
Width
1200 mm
47.244 inch
Height
1200 mm
47.244 inch
Weight
1200 kg
2646.7 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
