This machine is sold
Press brake AMADA - HFBO 100 - 3
CNC Pressbrake 3100 x 100 T Opperateur MACH-ID 6398| Make: | AMADA |
| Type: | HFBO 100 - 3 |
| Year: | 1998 |
Specifications
Max. bending length
3100 mm
122.047 inch
Distance between column
2700 mm
106.299 inch
Max. pressing force
100 T
100 T
Dis. Beam - Table
450 mm
17.717 inch
Beam stroke
180 mm
7.087 inch
Approch speed
8 mm/min.
8 mm/min.
Working speed
100 mm/min.
100 mm/min.
Return speed
80 mm/min.
80 mm/min.
Adjustment X-Axis back gauge
750 mm
29.528 inch
Number of controlled axis
4
4
Control
Opperateur
Opperateur
Dimensions (Estimate)
Length
3700 mm
145.669 inch
Width
2070 mm
81.496 inch
Height
2660 mm
104.724 inch
Weight
7500 kg
16542.2 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
