This machine is sold
Press brake AMADA - ITPS
MACH-ID 7180| Make: | AMADA |
| Type: | ITPS |
| Control: | Delem DA58 |
| Year: | 1989 |
Specifications
Max. bending length
2000 mm
78.74 inch
Distance between column
1520 mm
59.842 inch
Max. pressing force
50 T
50 T
Dis. Beam - Table
370 mm
14.567 inch
Beam stroke
100 mm
3.937 inch
Table Width
60 mm
2.362 inch
Troth beam
400 mm
15.748 inch
Approch speed
70 mm/min.
70 mm/min.
Working speed
10 mm/min.
10 mm/min.
Return speed
80 mm/min.
80 mm/min.
Adjustment X-Axis back gauge
1000 mm
39.37 inch
Number of controlled axis
4
4
Power
6.5 kW
6.5 kW
Dimensions (Estimate)
Length
2850 mm
112.205 inch
Width
2170 mm
85.433 inch
Height
2120 mm
83.464 inch
Weight
3750 kg
8271.1 lbs
Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
