HAEUSLER HBM-HY 7000 x 45 / 90 mm Flanging Bordelmaschine Dishing Mach4Metal 9830

Bordeuse de fonds bombé HAEUSLER - HBM-HY 7000 x 90

MACH-ID 9830

Marque:	HAEUSLER
Type:	HBM-HY 7000 x 90
Commande:	Bend Tronic
YOP:	2009

Question WhatsApp

HAEUSLER FLANGING MACHINE HBM-HY 8700 x 90 mm

Forming and Flanging rollers:
inclines positon 0 - 25 Degrees
Rotation sopeed 0 - 200 M/Min
Rapid adjustment speed 2500 mm/Min
Crawling speed 0 - 1200 mm/Min
Sleeve hydro mechanical rapid speed 6000 mm/Min

Infeed carriage:
Work piece weight 42.000 Kg
Max. dished head 8300 mm
Min. dished head 1900 mm
Speed 20 M/Sec
Centering Automatic

Data of Workpiece:
Cold 360 N/mm2 45 mm
Hot 360 N/mm2 90 mm
Min Knuckel Radius 100 mm
Max. Knuckel Radius 1200 mm
Min thickness dished 10 mm
Head diameter without device 2600 mm
Head diameter with device 1900 mm
Length off straight flange at flanged head 3,5 x thicness = 140 mm

Hydraulic tank 2000 Liter
10 sets knuckel head up to R-7300 mm
Power 350 kW
Form roller changing device in combi with lifgting sleeve
Auxiliary device for flanging heads from 1900 - 2600 x 25 mm thickness
Measuring device outer diameter and knuckle radius of flanged head

Optional Dishing Dies (Gray GG-25)
- RUW 925 with 1500 diameter x R 950 – 1300 mm
- RUW 1205 with 1500 diameter x R 1305 – 1700 mm
- RUW 1520 with 1500 diameter x R 1705 – 2200 mm
- RUW 1905 with 1500 diameter x R 2205 – 2800 mm
- RUW 2395 with diameter 1500 x R 2805 – 3500 mm
- RUW 2885 with diameter 1500 x R 3505 – 4300 mm
- RUW 3515 with diameter 1500 x R 4305 – 5200 mm
- RUW 4215 with diameter 1500 x R 5205 – 6200 mm
- RUW 4985 with diameter 1500 x R 6205 – 7300 mm

Caractéristiques

Métrique US Standard

Max. workpiece 8700 Ø 8700 Ø

Épaisseur maximum (acier) 90 mm 3.543 inch

Max. dishing radius 1250 mm 49.213 inch

Min. product Ø 1900 1900

Min. plate thickness 6 mm 0.236 inch

Min. dishing radius 2600 mm 102.362 inch

Dimensions (Estimation)

Longueur 14075 mm 554.133 inch

Largeur 2500 mm 98.425 inch

Hauteur 9725 mm 382.873 inch

Poids 212000 kg 467591.4 lbs

Important : les informations sur cette page ont été obtenues au meilleur de nos connaissances auprès des fabricants. L'exactitude n'est pas garantie mais les informations sont données de bonne foi. En conséquence, cela ne constitue pas une représentation ou des conditions contractuelles. Nous vous recommandons de vérifier tous les détails essentiels !
