Le tour multibroche MAZAK - INTEGREX 400 III-S
MACH-ID 9809| Marque: | MAZAK |
| Taper: | INTEGREX 400 III-S |
| Contrôle: | MAZATROL 640 MT PRO |
| Année: | 2005 |
- Only 4630 Cutting hours
- Automatic door
- 40 CAPTCO C6-Tool magazin
- Robot interface
- 5 Axis simulteneous package
- Sub spindel with C-Axis and 0,0001 Degree
- Internal Grundfos 15 Bar coolant
- Chip conveyor
- Optional tooling package with 40 holders
Caractéristiques
Dimensions (Estimation)
Important : les informations sur cette page ont été obtenues au meilleur de nos connaissances auprès des fabricants. L'exactitude n'est pas garantie mais les informations sont données de bonne foi. En conséquence, cela ne constitue pas une représentation ou des conditions contractuelles. Nous vous recommandons de vérifier tous les détails essentiels !
The Mazak INTEGREX 400-III S is a fairly heavy multi-tasking CNC turning/milling centre. In practical terms, it combines a CNC lathe, a 5-axis milling machine and a second spindle in one machine, allowing complex parts to be machined almost completely in one setup.
What does the “S” mean?
The important part is the S = second/sub spindle. So you have:
Main spindle → B-axis milling head → Y-axis → sub-spindle
This means you can turn and mill the front of a component, transfer it automatically to the sub-spindle, and then machine the back side. That's what makes this a true complete-machining / done-in-one machine.
The 400-III S primarily works with the B-axis milling head and the two spindles.
For the type of machines you normally evaluate, I'd classify the 400-III S as a serious, relatively high-spec Integrex of its generation. It was aimed at complex shafts, aerospace/energy components, hydraulic parts, general high-value subcontract work, etc.
